BMW R1150R Rebbster boxer engine…

14 November 2011

Diprodukasi dari tahun 2001~2006 hati hati mesinnya jenong kesamping… kalau habis jalan keslomot… panasss

Specification BMW R1150R Rebbster

Motor Type		Four-stroke, two cylinder, horizontally opposed “Boxer” engine, air cooled
Bore x Stroke		101 x 70.5 mm (3.97 x 2.77 in)
Displacement		1130 cc
Max Power		85 hp (62.5 KW) at 6,750 rpm
Max Torque		98 Nm / 72 ft lb at 5,250 rpm
Compression Ratio		10.3 : 1
Valves Per Cylinder		4
Valve Control		hc, using chain drive, cup tappets, push rod and rocker arm
Mixture Control / Engine Management		Electronic intake pipe injection/digital engine management: Bosch Motronic MA 2.4 with overrun fuel cut off, twin spark ignition (December 2002 on)
Emission Control		Closed loop 3 way catalytic converter
Engine Lubricating System		Wet sump

Power Transmission
Clutch		Single disc dry clutch, hydraulically operated
Gearbox		Constant mesh 6 speed gearbox
Gearbox Ratios		2.050 / 1.600 / 1.270 / 1.040 / 0.900 / 0.700
Rear Wheel Ratio		2.82
Drive		Shaft Drive

Electrical System
Ignition System		Electronic ignition, Bosch Motronic MA 2.4. Twin spark from December 2002
Alternator		700 W three phase alternator
Battery		12V / 19 Ah

Chassis
Type of Frame		Three section composite frame consisting of front & rear section, load bearing engine
Front wheel suspension		BMW Motorrad Telelever; stanchion diameter 35 mm, central strut, rebound damping adjustable
Rear wheel suspension		Die cast aluminium single sided swinging arm with BMW Motorrad Paralever; central strut, spring pre-load adjustable to continuously variable levels by mean of a hydraulic handwheel, rebound adjustable damping
Travel Front/Rear		120 / 135 mm (4.72 / 5.31 in)
Wheels		Die cast aluminium wheels
Wheel Rims, Front		3.50 x 17
Wheel Rims, Rear		5.00 x 17
Tyres, Front		120 / 70-ZR 17
Tyres, Rear		170 / 60-ZR 17
Brakes, Front		Twin disc 305 mm / 12 in floating, 4 piston fixed calipers. From 200?: EVO brake system with dual disc, floating brake discs, diameter 320 mm / 12.6 in, 4 piston fixed caliper
Brakes, Rear		Single disc brake 276 mm / 10.86 in diameter, double piston floating caliper
ABS		Special equipment BMW Motorrad Integral ABS (partially integral)

Dimensions/Weights
Length x Width x Height		2170 x 940 x 1220 mm (85.43 x 37.00 x 48.03 in)
Seat Height		800 mm / 31.49 in (special equipment low seat bench: 770 mm / 30.31 in
Wheel Base		1487 mm / 58.54 in
Castor (in Normal Position)		127 mm / 5.00 in
Steering Head Angle (in Normal Position)		61.9 degrees
Fuel Tank Useable Volume		20.5 litres / 4.50 gal / 5.41 gal US
Reserve		4.0 litres / 0.87 gal / 1.05 gal US
Unladen Weight with Full Tank		238 Kg / 524 lb
Dry Weight		218 Kg / 480 lb
Max. Permissible Weight		450 Kg / 991 lb
Payload (with Standard Equipment)		212 Kg / 466 lb
Fuel Consumption over 100 Km @ constant 90 Kph		4.6 litres / 61 mpg / 51 mpg US
Fuel Consumption over 100 Km @ constant 120 Kph		5.7 litres / 49 mpg / 41 mpg US
Fuel Type		Unleaded Premium minimum octane rating 95 (RON)
Top Speed		Approx. 197 Kph / 122 mph
